LSLV0450H100-4COND(PLUS) - 60 hp 3-Phase Variable Frequency Drive (VFD)

Order Code: 67310013PL

The LSLV0450H100-4COND(PLUS) is a powerful and versatile 60 horsepower variable frequency drive (VFD) designed for 3-phase applications. Part of the H100+ Series, this VFD offers advanced control and energy-saving capabilities for fan and pump systems.

Features

• Horsepower: 60 hp
• Input Phase: 3 Phase
• Input Voltage: 400-480V, 3 Phase
• Output: 3 Phase Output
• Torque Load: Constant/Variable (CT/VT)
• Drives - Type of Drive: Fan and Pump/HVAC
• Housing/Enclosure: IP20
• Series: H100+ Series
• Options: Built-In DC Reactor, Enclosed, Integrated CANopen/Modbus-RTU, Keypad
• Outdoor Rated: No
• H100+ Enhancements: No-flow control, Flow monitoring, PI auxiliary (suction/level/vacuum) control, Over-cycling protection, Differential level detection, Low/high feedback detection, Setpoint timeout, Current limit, Thrust bearing control, Pump minimum speed, Improved Hand-Off-Auto keypad, Power-On run for keypad command, Lead-lag, Enhanced PID performance, Simplify PID group, Various sleep mode and method, Selectable wake-up method (absolute, deviation), Wake-up disable mode, Backspin timer, Single phase protection, Dual rating (normal or heavy duty applications)

Specifications

• Model: LSLV0450H100-4COND(PLUS)
• Order Code: 67310013PL
• Alternate Part Numbers: 67310013PL, 6731001300 (Latest Version of LSLV0450H100-4COND)
• Horsepower: 60 hp
• Input Voltage: 400-480V, 3 Phase
• Output: 3 Phase
• Enclosure: IP20

Applications

Ideal for a wide range of fan and pump applications, including:

• HVAC Systems
• Industrial Pumps
• Cooling Systems
• And More

The H100+ Series offers an eco-friendly and energy-saving solution for your fan and pump systems.
